Fluke 1550C FC KIT Insulation Resistance Tester Kit

Name: Fluke 1550C FC KIT Insulation Resistance Tester Kit
Brand: Fluke
SKU: 00221
Availability: InStock

Store / Electrical

0.00 AED

In stock

Product Details

UPC: 095969550987

Brand: Fluke

Insulation Range: 5 kV

DC voltage Range: 250 V/500 V/1000 V/2500 V/5000 V

Capacitance Range: 0.01 μF to 15.00 μF

Leakage Current: 1 nA to 2 mA

Fluke 1550C FC KIT Insulation Resistance Tester Kit

The Fluke 1550C FC KIT Insulation Resistance Tester Kit is a high-quality, versatile tool for conducting insulation testing in various electrical applications. This kit offers a range of features that make it a valuable asset for professionals in the field. The Fluke 1550C FC 5 kV Digital Insulation Tester is designed to provide insulation testing for up to 5 kV, making it ideal for high-voltage equipment and systems.

Key Features and Benefits

The Fluke 1550C FC 5 kV Insulation Tester Kit comes with several key features that set it apart from other insulation testers. Some of the notable features include:
Remote Operation: The tester can be configured, started, and stopped remotely using the Fluke Connect® app, allowing users to maintain a safe distance from energized equipment.
Real-Time Trending: The device provides easy-to-see visual cues through real-time trending, making it easier to interpret test results.
Data Collection and Analysis: The Fluke Connect app allows for easy data collection and storage in the cloud, enabling analysis and preventive maintenance.
Versatile Testing Capabilities: The kit offers a wide range of testing capabilities, including capacitance and leakage current measurement, resistance measurements up to 2 TΩ, and timer settings for timed tests.

Applications

The Fluke 1550C FC 5 kV Insulation Tester Kit is suitable for various applications, including:

High-Voltage Equipment: Its 5 kV insulation testing capability makes it well-suited for testing high-voltage equipment and systems.
Preventive Maintenance: The ability to store test results in the cloud and the remote operation feature make it an excellent tool for preventive maintenance and data analysis.

In conclusion, the Fluke 1550C FC KIT Insulation Resistance Tester Kit is a reliable and advanced solution for insulation testing requirements. Its remote operation, real-time trending, and data collection capabilities make it a valuable tool for professionals in the electrical industry. With its versatile testing features and ease of use, this kit is well-equipped to meet the demands of various insulation testing applications.

Fluke 1550C FC KIT Insulation Resistance Tester Kit specifications:

Electrical Specifications
The tester's accuracy is specified for one year after calibration at operating temperatures of 0°C to 35°C. For operating temperatures outside the range (-20°C to 0°C and 35°C to 50°C), add ± .25% per °C, except on the 20% bands add ± 1% per °C.
Insulation Resistance Measurement
Test voltage (DC)
250 V	Range	< 250 kΩ,
		250 kΩ to 5 GΩ
		5 GΩ to 50 GΩ
		> 50 GΩ
	Accuracy (± reading)	Unspecified
		5%
		20%
		Unspecified
500 V	Range	< 500 kΩ
		500 kΩ to 10 GΩ
		10 GΩ to 100 GΩ
		> 100 GΩ
	Accuracy (± reading)	Unspecified
		5%
		20%
		Unspecified
1000 V	Range	< 1 MΩ
		1 MΩ to 20 GΩ
		20 GΩ to 200 GΩ
		> 200 GΩ
	Accuracy (± reading)	Unspecified
		5%
		20%
		Unspecified
2500 V	Range	< 2.5 MΩ
		2.5 MΩ to 50 GΩ
		50 GΩ to 500 GΩ
		> 500 GΩ
	Accuracy (± reading)	Unspecified
		5%
		20%
		Unspecified
5000 V	Range	< 5 MΩ
		5 MΩ to 100 GΩ
		100 GΩ to 1 TΩ
		> 1 TΩ
	Accuracy (± reading)	Unspecified
		5%
		20%
		Unspecified
Bar graph range	0 to 1 TΩ (1550C) - 0 to 2 TΩ (1555)
Insulation test voltage accuracy	-0%, +10% at 1 mA load current
Induced AC mains current rejection	2 mA maximum
Charging rate for capacitive load	5 seconds per μF
Discharge rate for capacitive load	1.5 s/μF
Leakage current measurement	Range	1 nA to 2 mA
	Accuracy	± (5% + 2 nA)
Capacitance measurement	Range	0.01 μF to 15.00 μF
	Accuracy	± (15% rdg + 0.03 μF)
Timer	Range	0 to 99 minutes
	Resolution setting	1 minute
	Resolution indication	1 second
Live circuit warning	Warning range	30 V to 660 V AC/DC, 50/60 Hz
	Voltage accuracy	± (15% + 2 V)
Software specifications	FlukeView Forms™ basic software requires a PC running Windows XP, Windows Vista , Windows 7 or Windows 8.
General Specifications
Display	75 x 105 mm
Power	12 V lead-acid rechargeable battery, Yuasa NP2.8-12
Charger Input (AC)	85 V to 250 V AC 50/60 Hz 20 VA
Dimensions	269 x 277 x 160 mm (10.6 x 10.9 x 6.3 in)
Weight	3.7 kg (8.2 lb)
Temperature (operating)	-20°C to 50°C (-4°F to 122°F)
Temperature (storage)	-20°C to 65°C (-4°F to 149°F)
Humidity	80% to 31°C decreasing linearly to 50% at 50°C
Altitude	2000 m
