Fluke 719Pro 150G Fabulous Electric Pressure Calibrator

Name: Fluke 719Pro 150G Electric Pressure Calibrator | Uazon
Brand: Fluke
SKU: 00248
Availability: InStock

Store / Calibrators

0.00 AED

In stock

Product Details

Brand: Fluke

Range: -12 to 150 psi / -0.8 to 10 bar

Resolution: 0.01 psi / 0.001 bar

Accuracy: ±0.025% of full scale, 6 months, ±0.035% of full scale, 1 year

Functions: mA DC (simulation and measurement), Volts DC (measurement only)

Power: Eight (8) standard Alkaline AA batteries

Operating Temp.: -10°C to +50°C

Storage Temp.: -20°C to +60°C

Size: 24.13 x 11.18 x 7 cm (9.5 x 4.4 x 2.8 in)

Weight: With holster 1.2 kg (2.5 lb)

Loop Power Range: 24 V DC

Fluke 719pro 150g pressure calibrator

The Fluke 719Pro 150G Electric Pressure Calibrator is a versatile and reliable tool used for calibrating high-accuracy transmitters, pressure switches, and gauges. It features an integrated electric pump for one-handed pressure calibration, making it ideal for various applications. The calibrator has a range of -12 to 150 psi and a resolution of 0.001 psi, ensuring accurate measurements. It also offers a precision pressure adjust vernier for easy and accurate pressure calibration, and a large backlit screen that displays three parameters at once, including pressure measurement, sourced/simulated or measured mA values, and temperature measured by an optional RTD probe.

The Fluke 719 Pro 150 G Electric Pressure Calibrator is designed for ease of use and versatility. It eliminates over-pressurization and allows the user to program target pressures for pumping with the pressure calibrator pump limit. The unit includes a full functioning loop calibrator that sources, simulates, and measures mA signals, making it a comprehensive tool for various calibration needs. Additionally, it features inputs for mA, voltage, switch contacts, and an RTD probe, providing flexibility for different testing requirements.

Fluke 719Pro 150G Review

This electric pressure calibrator is suitable for a wide range of industries, including petrochemical, oil and gas, pharmaceutical, water and wastewater, food and beverage, and power generation. Its rugged, handheld design and high accuracy make it an ideal test tool for various calibration tasks. The Fluke 719Pro 150G Electric Pressure Calibrator is a valuable instrument for professionals who require precise and reliable pressure calibration in their day-to-day work.for Fluke 719pro 150g price please visit Uazon website.

In summary, the Fluke 719 Pro 150G Electric Pressure Calibrator is a feature-rich and reliable instrument that offers high accuracy, ease of use, and versatility, making it suitable for a wide range of applications in different industries. Its integrated electric pump, large backlit screen, and comprehensive functionality make it an ideal tool for calibrating pressure instruments and ensuring accurate measurements in various settings.

Fluke 719 Pro 150G Specifications

Measurement
Fluke 719 150G	Range	-12 to 150 psi / -0.8 to 10 bar
	Resolution	0.01 psi / 0.001 bar
Accuracy	±0.025% of full scale, 6 months
	±0.035% of full scale, 1 year
Temperature effect (all ranges)	Add ±0.002% F.S./°C for temps outside of 15°C to 35°C
Dry air and non-corrosive gas only
No effect on accuracy on all functions from 15°C to 35°C
Function	Range	Resolution	Accuracy (1 year)
mA DC (simulation and measurement)	0-24 mA DC	0.001 mA	±0.015% of reading ±2 counts
	1000 ohm maximum load in mA source, 26 V DC maximum voltage in mA simulate
Volts DC (measurement only)	30 V DC	0.001 V	±0.015% of reading ±2 counts
	No AC voltage measurement, do not exceed 30 V DC
Temperature (measurement only, Pt100 RTD)	-50 to 150°C	0.01°C	Temperature ±0.1°C (0.2°F)
	(-50°F to 302°F)	0.01°F
	±0.25°C (±0.45°F) combined uncertainty when using 720 RTD probe (optional accessory)
Loop power supply	24 V DC	N/A	24 mA at 24 V
Temperature effect (all functions)	-	-	Add ±0.002% F.S./°C for temps outside of 15°C to 35°C
	No effect on accuracy on all functions from 15°C to 35°C
Environmental
Operating temperature	-10°C to +50°C
Storage temperature (with batteries)	Per battery manufacturer's specification within storage specification below
Storage temperature (without batteries)	-20°C to +60°C
Power Requirements
Battery	Eight (8) standard Alkaline AA batteries
Battery life	300 pump cycles to 150 psi minimum; 1000 pump cycles to 30 psi; 100 pump cycles to 300 psi minimum
Physical
Dimensions (H x W x D)	24.13 x 11.18 x 7 cm (9.5 x 4.4 x 2.8 in)
Weight	With holster 1.2 kg (2.5 lb)
Connections
Pressure	1/8 inch female NPT
Electrical	Standard banana jacks
RTD	4 pin miniature circular
External module	6 pin miniature circular
Engineering Units (Configurable)
psi, bar, mbar, kPa, kgcm ² , cmH ₂ O @ 4°C, cmH ₂ O @ 20°C, mH ₂ O @ 4°C, mH ₂ O @ 20°C, inH ₂ O @ 4°C, inH ₂ O @ 20°C, inH ₂ O @ 60°F, mmHg @ 0°C, inHg @ 0°C, ftH ₂ O @ 4°C, ftH ₂ O @ 20°C, ftH ₂ O @ 60°F
