Megger MIT415/2 CAT IV Insulation Tester
0.00 AED
In stock
Product Details
Brand:
Megger
Insulation Range:
10 V - 1 GΩ, 25 V - 2 GΩ, 50 V - 5 GΩ, 100 V - 10 GΩ, 250 V - 20 GΩ, 500 V - 50 GΩ
Test Voltage Range:
10 V, 25 V, 50 V, 100 V, 250 V, 500 V
DC voltage Range:
600 V Trms AC and DC voltage measurement
AC voltage Range:
600 V Trms AC and DC voltage measurement
Continuity testing Range:
0,01 Ω to 99,9 Ω (0 to 100 Ω on analogue scale)
Leakage Current:
0 µA 2000 µA
Input Overload Protection:
CAT IV 600 V rating
DAR:
Automatically
PI:
Automatically
Operating temperature:
-10 to +55 °C
Storage temperature:
-25 to +70 °C
Altitude:
2000 m
Dimensions:
Instrument 228 mm x 108 mm x 63 mm (9.00 in x 4.25 in x 2.32 in)
Weight:
600 g
Power:
6 x 1.5 V cells type IEC LR6 (AA, MN1500, HP7, AM3 R6HP) Alkaline, 6 x 1.2 V NiMH rechargeable cells may be used
Display:
Analogue: 1 GΩ full scale
Short Circuit Current:
2 mA +0% -50% to EN 61557-2 (2007)
Voltage Measurement Measuring Range:
10 V, 25 V, 50 V, 100 V, 250 V, 500 V
Megger MIT415/2
The Megger MIT415/2 CAT IV Insulation Tester is a robust and reliable instrument designed for insulation testing in various electrical applications. It is particularly suited for use in environments where safety and compliance with regulations are paramount, making it an essential tool for electricians, engineers, and maintenance personnel.
Key Features
- High Voltage Testing: The MIT415/2 can perform insulation resistance tests at voltages up to 1000V, allowing users to assess the integrity of insulation in a wide range of electrical systems.
- Multiple Test Voltages: This tester offers selectable test voltages of 250V, 500V, and 1000V. This flexibility enables users to choose the appropriate voltage for different insulation materials and applications.
- True RMS Measurement: The device is equipped to measure True RMS voltage, which provides accurate readings of non-linear loads, ensuring reliable performance in real-world conditions.
- Continuity Testing: In addition to insulation testing, the MIT415/2 also performs continuity tests, making it a versatile tool for comprehensive electrical testing.
- Weatherproof Design: The tester features a weatherproof casing rated to IP54 standards. This protection ensures durability and reliability even in challenging environments, such as outdoor or industrial settings.
- Shock-Resistant Cladding: The over-moulded design provides shock absorption, further enhancing the instrument's resilience during use.
- Remote Testing Capability: The MIT415/2 supports remote testing via a SP5 remote switch probe, allowing users to initiate tests from a safe distance.
Applications
The Megger MIT415/2 is widely used across various industries:
- Electrical Installation Testing: It is primarily utilized for testing the insulation integrity of new electrical installations before they are put into service.
- Maintenance and Troubleshooting: Electrical maintenance teams use this tester to identify potential insulation failures in existing systems, helping to prevent unexpected outages or equipment damage.
- Compliance Verification: The device assists organizations in meeting safety standards and regulations by providing accurate insulation resistance measurements.
In summary, the Megger MIT415/2 CAT IV Insulation Tester is an essential instrument for professionals involved in electrical testing and maintenance. Its combination of high voltage capabilities, user-friendly design, and robust construction makes it a reliable choice for ensuring the safety and performance of electrical installations.
Megger MIT415/2 Specifications
| Insulation Nominal test voltages | 10 V, 25 V, 50 V, 100 V, 250 V, 500 V |
| Insulation resistance range | 10 V - 1 GΩ |
| 25 V - 2 GΩ | |
| 50 V - 5 GΩ | |
| 100 V - 10 GΩ | |
| 250 V - 20 GΩ | |
| 500 V - 50 GΩ | |
| Range Full Scale Accuracy | 500 V ±3% ±2 digits ±0.4% per GΩ |
| 250 V ±3% ±2 digits ±0.8% per GΩ | |
| 100 V ±3% ±2 digits ±2.0% per GΩ | |
| 50 V ±3% ±2 digits ±4.0% per GΩ | |
| 25 V±3% ±2 digits ±2.0% per 100 MΩ | |
| 10 V±3% ±2 digits ±2.0% per 100 MΩ | |
| Analogue range | 1 GΩ full scale |
| Resolution | 0.01 MΩ |
| Short circuit current | 2 mA +0% -50% |
| Open circuit terminal voltage | -0% + 20% ±1 V |
| Test current on load | 1 mA at min. pass value of insulation specified in BS7671, HD384and IEC364, 2 mA max. |
| Leakage current range | 0 µA 2000 µA |
| Leakage current | 10% ±3 digits |
| Voltage display | 3% ±3 digits ±0.5% of rated voltage |
| Timer | 1, 2, 3, 4, 5, 6, 7, 8, 9, 10 minute count down in seconds |
| Continuity | |
| Measurement | 0,01 Ω to 99,9 Ω (0 to 100 Ω on analogue scale) |
| Accuracy | ±2% ±2 digits (0 to 100 Ω ) |
| Open circuit voltage | 5 V ±1 V |
| Test current | 200 mA (±1 mA) (0.01 Ω to 9.99 Ω )20 mA (±1 mA ) (10.0 Ω to 99.9 Ω ) |
| Zero offset at probe tips | 0,10 Ω typical |
| Lead resistance zeroing | Up to 9.00 Ω |
| Buzzer | Variable limit 1 Ω , 2 Ω , 5 Ω , 10 Ω , 20 Ω |
| Resistance | |
| Measurement | 0.01 kΩ to 1000 kΩ (0 to 1 MΩ on analogue scale) |
| Accuracy | ±3% ±2 digits |
| Open circuit voltage | 5 V ±1 V |
| Short circuit current | 20 µA ±5 µA |
| Other | |
| Voltage range | 0 to 600 V d.c. ±2% ±2 digits |
| 10 mV to 600 V TRMS sinusoidal (40 to 400 Hz) ±2% ±1 digit | |
| 0 to 1000 V on analogue scale | |
| Unspecified input level 0 - 10 mV (40 to 400 Hz) | |
| Temperature coefficient | <0,1% per °C up to 1 GΩ |
| <0,1% per °C above 1 GΩ | |
