Megger MIT420/2 Insulation Resistance Tester

Megger MIT420 2 Insulation Tester

The Megger MIT420/2 Insulation Resistance Tester is an advanced instrument designed for the electrical testing needs of professionals in the industrial, commercial, and utility sectors. Known for its reliability, accuracy, and ease of use, the MIT420/2 is essential for ensuring the integrity and safety of electrical systems. It offers a comprehensive solution for testing insulation resistance, continuity, and voltage.

The Megger MIT420/2 Insulation Resistance Tester is an indispensable tool for professionals requiring reliable and precise insulation resistance measurements. Its advanced features, user-friendly interface, and robust design make it a top choice for a variety of electrical testing applications.

Megger MIT420/2 Insulation Resistance Tester App

Electrical Installations: Verify insulation integrity in residential, commercial, and industrial electrical installations.

Preventive Maintenance: Regularly check the insulation resistance of electrical equipment to prevent failures.

Utility Sector: Conduct routine testing of transformers, switchgear, and other utility equipment.

Manufacturing: Test the insulation resistance of manufactured electrical components to ensure quality control.

Troubleshooting: Diagnose insulation problems in wiring, motors, and other electrical devices.

Megger MIT420/2 Insulation Resistance Tester Key Features

High-Voltage Testing: Insulation testing up to 1000V, ideal for a wide range of applications.

Digital Display: Large, clear backlit display for easy reading of measurements.

Multiple Test Modes: Includes insulation resistance, continuity, and voltage testing modes.

Data Hold and Storage: Allows for data hold to freeze readings and internal storage for up to 200 test results.

Automatic Discharge: Ensures safety by automatically discharging capacitance after insulation tests.

Durable Design: Robust construction with a protective rubber boot for enhanced durability in field conditions.

Safety Rated: CAT IV 600V rating ensures high safety standards.

Megger MIT420/2 Insulation Resistance Tester Specifications

Insulation Test Voltages	50V, 100V, 250V, 500V, 1000V
Insulation Resistance Range	10 kΩ to 200 GΩ
Continuity Testing Range	0.01 Ω to 1 MΩ
Voltage Testing Range	0 to 600V AC/DC
Accuracy	±2% of reading
Display	LCD with backlight
Power Supply	6 x AA batteries
Battery Life	Up to 60 hours continuous use
Dimensions	203 x 148 x 78 mm
Weight	1 kg
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Protection Rating	IP54
Data Storage	Up to 200 test results
Communication Interface	USB for data transfer
Standards Compliance	IEC 61010-1, IEC 61557, EN 61557
Accessories Included	Test leads, probes, carrying case, user manual
