CEM DT-5530 Insulation Tester

CEM DT-5530 Insulation Tester

Store / Electrical
0.00 AED
In stock
Product Details

CEM DT-5530 Insulation Tester

The CEM DT-5530 Insulation Tester is a professional-grade device designed for accurately measuring the insulation resistance of electrical systems and components. This tester is essential for ensuring the safety and reliability of electrical installations, making it an indispensable tool for electricians, engineers, and maintenance personnel.

A standout feature of the CEM DT-5530 is its ability to deliver a 1mA test current for the MegOhm range at rated voltage. This capability is essential for accurately measuring high resistance values, which are indicative of the integrity of insulation in wiring and electrical devices. The precision afforded by this 1mA test current enables the detection of potential insulation breakdowns, which could otherwise lead to dangerous electrical failures.

CEM DT-5530 Key Features

  • Enhanced Safety
  • Versatility
  • Ease of Use
  • Reliability

CEM DT-5530 Specifications

Specifications
Function Range Max Resolution Basic accuracy
Voltage AC 750V 1V ±1.2%rdg ±10dgts
Voltage DC 1000V 1V ±0.8%rdg ±3dgts
Resistance 200Ω, 2000Ω 0.1Ω, 1Ω ±1%rdg ±2dgts
Insulation Resistance 200MΩ, 2000MΩ 20MΩ(5520 only) 100kΩ~1MΩ 10kΩ ±3.5%rdg ±5dgts ±3.5%rdg ±5dgts
Test Voltage 250V-200MΩ/500V-200MΩ/1000V-2000MΩ, (500V-20MΩ only 5520)
Continuity Test Active Sound Level: ≤40Ω, Test current ≤200mA
Operating Temp 0ºC~40ºC (<80%R.H.)
Storage Temp -10ºC~60ºC (<70%R.H.)
Power Source 1.5V “AA” size Battery x 6
