Flir DM91 Industrial Trms Multimeter
1,116.00 AED
In stock
Product Details
Brand:
Flir
AC Voltage Range:
600.0 mV, 1000.0V
DC Voltage Range:
600.0 mV, 1000.0V
AC Current Range:
400.0 mA, 10.00 A
DC Current Range:
400.0 mA, 10.00 A
AC Voltage Overload Protection:
CAT IV-600V, CAT III-1000V
DC Voltage Overload Protection:
CAT IV-600V, CAT III-1000V
Resistance Range:
50.00 MΩ
Capacitance Range:
10.00 mF
Frequency Range :
100.00 kHz
Diode test:
1.500 V
Temperature Range:
-40°C to 400°C, -40°F to 752.0°F
Power:
4 AAA batteries; optional TA04 Li-Poly rechargeable battery
Dimension:
200 × 95 × 49 mm (7.9 × 3.7 × 1.9 in)
Weight:
536 g (18.9 oz)
Continuity buzzer:
20 Ω and 200 Ω
FLIR DM91
The FLIR DM91 Industrial TRMS Multimeter is a high-performance digital multimeter designed for professionals in electrical and electronic applications. It combines advanced measurement capabilities with robust features, making it suitable for troubleshooting and diagnostics in various industrial settings.
Key Features
Measurement Capabilities
- Voltage Measurement: The DM91 can measure both AC and DC voltages up to 1000 V, ensuring it can handle a wide range of applications, from low-voltage circuits to high-voltage systems.
- True RMS Measurement: This multimeter provides True RMS readings, which are essential for accurately measuring non-sinusoidal waveforms commonly found in variable frequency drives (VFDs) and other electronic devices.
- Current Measurement: It measures AC and DC currents up to 10 A and can also measure microamps and milliamps, making it versatile for various electrical tasks.
- Resistance, Capacitance, and Temperature: The DM91 can measure resistance up to 6 MΩ, capacitance up to 10 mF, and temperature using a Type-K thermocouple with a range from -40°C to 400°C (-40°F to 752°F).
- Frequency Measurement: The multimeter can measure frequencies up to 100 kHz, which is useful for testing and diagnosing electronic circuits.
Data Logging and Connectivity
- Datalogging Capability: The DM91 features an onboard storage capacity for up to 40,000 measurements, allowing users to log data over time for analysis and documentation.
- Bluetooth Connectivity: This multimeter includes Bluetooth® technology, enabling users to connect to FLIR’s METERLiNK® and other applications. This feature allows for the integration of measurement data into thermal images captured by compatible FLIR infrared cameras.
- Wireless Sharing: Users can wirelessly send readings to mobile devices running FLIR Tools or the FLIR InSite workflow management application, enhancing workflow efficiency.
Design and Durability
- User-Friendly Interface: The DM91 is designed with an intuitive interface and enhanced ergonomics, making it easy to navigate and operate even in challenging conditions.
- Rugged Construction: Built to withstand tough environments, the DM91 is drop-tested and has a CAT IV-600V and CAT III-1000V safety rating, ensuring reliable performance in industrial settings.
- LED Worklight: The built-in LED worklight provides illumination in dimly lit areas, facilitating easier readings and measurements.
- Battery Options: The multimeter operates on 4 AAA batteries or an optional lithium polymer battery, with a long battery life of approximately 110 hours for alkaline batteries and up to 500 hours for lithium.
Applications
The FLIR DM91 is ideal for a variety of applications, including:
- Electrical Troubleshooting: Perfect for diagnosing electrical systems in industrial, commercial, and residential settings.
- HVAC/R Systems: Useful for technicians working on heating, ventilation, air conditioning, and refrigeration systems.
- Maintenance and Repair: Essential for maintenance professionals needing accurate measurements for preventive maintenance and repair tasks.
In summary, the FLIR DM91 Industrial TRMS Multimeter is a versatile and reliable tool that combines advanced measurement capabilities with user-friendly features, making it suitable for a wide range of electrical and electronic applications. Its robust design, connectivity options, and extensive measurement functions make it an invaluable asset for professionals in the field.
FLIR DM91 Specifications
| Feature | |
| Connectivity | Bluetooth® |
| Data Logging & Storage | 1 file of 40k scalar measurements |
| Measurements - Both Models | Basic Accuracy |
| True RMS | Yes |
| AC / DC Volts | ±1.0% / 0.09% |
| AC / DC mVolt | ±1.0% / 0.5% |
| VFD AC Volts | ±1.0% |
| AC / DC LoZ V | ±2.0% |
| AC / DC Amps | ±1.5% / 1.0% |
| AC / DC mAmps | ±1.5% / 1.0% |
| AC / DC µAmps | ±1.0% |
| Resistance | ±0.9% |
| ±3.0% | |
| Capacitance | ±1.9% |
| Diode Test | ±0.9% |
| Frequency Counter | ±0.1% |
| Temperature, Type-K Thermocouple | ±1.0% ± 5.4°F (±1.0% ± 3°C) |
| Additional Measurements | |
| Continuity Check | 20 Ω and 200 Ω |
| Measuring Rate | 3 samples per second |
| General Information | DM91 |
| Auto Power Off | Yes |
| Worklights | Yes |
| Battery | 3 AA batteries; optional TA04 Li-Poly rechargeable battery |
| Drop Test | 3 m |
| IP Rating | IP40 |
| Safety Category Rating | CAT IV-600V, CAT III-1000V |
| Size (L x W x H) | 200 x 95 x 49 mm (7.9 x 3.7 x 1.9 in) |
| Weight | 535 g (18.8 oz) |
| Warranty | Limited lifetime warranty |
