The Fluke 707 loop calibrator, a precision instrument for current loop measurement and calibration, featuring a compact design and advanced functionality for accurate and efficient testing in industrial settings.

Fluke 707 Advanced Current Loop Calibrator with Quick Click Knob

Name: Fluke 707 Current Loop Calibrator | Uazon
Brand: Fluke
SKU: 00276
Availability: InStock

Store / Calibrators

0.00 AED

In stock

Product Details

UPC: 095969107150

Brand: Fluke

Ranges: 0 to 24 mA

Resolution: 0 to 24 mA

Accuracy: 0.015% Rdg + 2 LSD

Power: One 9 V battery Alkaline

Loop compliance voltage: While measuring mA, 24 V

Dimensions (L x W x D): 152 x 70 x 41 mm

Weight: 224 g (340 g including holster)

Operating temperature: -10°C to 55°C

Fluke 707 loop calibrator

The Fluke 707 Current Loop Calibrator is a high-performance solution for calibration, repair, and maintenance of current loops. This precision calibrator is designed to provide accurate and efficient pressure calibration, ensuring the proper functioning of pressure instruments and systems.

The 700G Series Pressure Gauges are high-accuracy digital pressure test gauges, accurate to 0.05 % FS, and can be used as a calibration reference or in any application where high-accuracy pressure measurement is required.

707 Loop Calibrator Key Features

The Fluke 707 Current Loop Calibrator offers a wide pressure range, high accuracy, and portability. It is compatible with most hydraulic and pneumatic test pumps, ensuring its versatility and flexibility in pressure calibration procedures.

The calibrator is accurate to 0.05 % FS and can be used as a calibration reference or in any application where high-accuracy pressure measurement is required.

Applications

This pressure gauge calibrator is suitable for a wide range of applications, including the calibration of pressure instruments in manufacturing, petrochemical, and pharmaceutical industries. Its high accuracy and reliability make it an essential tool for ensuring the proper operation of pressure systems and equipment.

Benefits

The Fluke 707 Current Loop Calibrator offers several benefits, such as the ability to perform accurate and efficient pressure calibrations, portability for on-site use, and compatibility with a variety of pressure instruments. The calibrator's high-quality construction and design ensure long-term reliability and performance.

In conclusion, the Fluke 707 Current Loop Calibrator is a powerful and versatile instrument designed for precise pressure calibration. Its wide pressure range, high accuracy, and portability make it an essential tool for professionals who require reliable pressure calibration in industrial environments.

The calibrator's compatibility with a variety of pressure instruments and its high-quality construction ensure accurate and efficient pressure calibration, making it a valuable asset for professionals in various industries.

Fluke 707 Current Loop Calibrator Specifications:

Current measurement	Range	0 to 24 mA
	Resolution	0.001 mA
	Accuracy	0.015% Rdg + 2 LSD
Current sourcing	Range	0 to 20 mA or 4 to 20 mA
	Accuracy	0.015% Rdg + 2 LSD
	Drive capability	1200 Ω 950 Ω at 20 mA in HART mode
Current simulation	Range	0 to 20 mA or 4 to 20 mA
	Accuracy	0.015% Rdg + 2 LSD
	Ext. loop voltage requirement	12-30 V
Loop power	While measuring mA, 24 V
Voltage measurement	Range	0 to 28 V DC
	Resolution	1 mV
	Accuracy	0.015% Rdg + 2 LSD
Environmental Specifications
Operating temperature	-10°C to 55°C
Storage temperature	-30°C to 60°C
Humidity (without condensation)	0 to 90% (0°C to 35°C); 0 to 70% (35°C to 55°C)
Temperature coefficient	-10°C to 18°C, 28°C to 55°C, ±.005% of range per °C
Safety Specifications
Safety	CSA C22.2 No. 1010.1:1992
EMC	EN50082-1:1992 and EN55022:1994 Class B
Maximum voltage	30 V
Mechanical and General Specifications
Size	152 x 70 x 41 mm
Weight	224 g (340 g including holster)
Batteries	One 9 V battery Alkaline
Warranty	Three years
Shock and vibration	Per MIL-T-28800 for a Class 2 Instrument
Display current and % of span	Yes
Auto step, auto ramp	Yes
Span check	Yes
