HIOKI 3281 DIGITAL CLAMP ON HiTESTER
500.00 AED
In stock
Product Details
Brand:
Hioki
Jaw Diameter:
φ 33 mm (1.30 in)
AC Current Range:
30.00 to 600 A
AC Voltage Range:
300.0 to 600 V
Applicable model:
1000 Ω to 10.00 kΩ
Frequency Range:
30.0 Hz to 1000 Hz
Dimension:
62 mm W × 218 mm H × 39 mm D
Power Supply:
Stacked manganese battery (6F22) ×1
HIOKI 3281 DIGITAL CLAMP ON HiTESTER
The Hioki 3281 Digital Clamp-On HiTester is a versatile electrical testing equipment used by experts in electrical engineering and maintenance. This gadget, also known as a clamp metre, allows users to easily and precisely measure numerous electrical properties.
The ability to measure AC current up to a given range, as specified in the specifications, is one of the primary features of the Hioki 3281 Digital Clamp-On HiTester. It is a simple and non-invasive means to measure current flowing through a conductor since it may be clamped around the wire without disrupting the circuit. This digital clamp metre can also measure other electrical properties like AC voltage, resistance, and frequency.
The instrument has a digital display that gives clear and precise readings, making it user-friendly and appropriate for both experts and technicians. It is commonly utilised in electrical circuit troubleshooting, normal maintenance, and electrical measurement verification in a variety of applications.
Overall, the Hioki Clamp-On HiTester is a useful tool for anyone who works with electrical systems since it streamlines the process of measuring and monitoring electrical characteristics, resulting in more efficient electrical system maintenance and diagnostics.
HIOKI CM3281 Introduction
HIOKI 3281 Clamp meter
- Measure current up to 600 A
- Multi-functional testing of AC current, voltage, frequency, resistance and wave peak value
- Non-fuse type protects up to 600 V AC
HIOKI 3281 Clamp meter Specifications
| Specification | Details |
| AC Current | 30.00 to 600 A, 3 ranges (40 Hz to 1 kHz, True RMS) |
| AC Voltage | 300.0/ 600 V, (40 Hz to 1 kHz, True RMS) |
| Crest Factor | 2.5 or less (1.7 at 600 A, 1.7 at 600 V) |
| Frequency | 30.0 Hz to 1000 Hz, Basic accuracy: ±0.3 % rdg. ±1 dgt. |
| Resistance | 1000 Ω/ 10.00 kΩ |
| Core Jaw Diameter | φ 33 mm (1.30 in) |
| Dimensions (W × H × D) | 62 mm (2.44 in) W × 218 mm (8.58 in) H × 39 mm (1.54 in) D |
| Mass | 350 g (12.3 oz) |
