Megger PAT150 Handheld Portable Appliance Testers
0.00 AED
In stock
Product Details
Megger PAT150 Handheld Portable Appliance Testers
The Megger PAT150 series includes handheld portable appliance testers designed for easy and efficient testing of electrical safety on portable appliances. These testers are widely used in various environments to ensure compliance with safety standards.
Featuring rubber-armored cases and scratch-resistant hardened glass, the PAT100 series is exceptionally durable. These battery-powered testers are ideal for environments lacking a convenient or safe electrical supply, such as construction sites and warehouses.
Megger PAT150 Key Features
- Simple ‘tick/cross’ or ‘pass/fail’ indication plus measurement
- Tough, rubber armoured with built-in front cover, hardened, scratch-proof display window
- Includes 250 V insulation and leakage testing for safe IT testing and surge protected devices
- Testing portable and fixed electrical equipment
- 10 mA and 30 mA portable RCD lead testing
- Adjustable PASS test limits
- Substitute and mains powered leakage testing
- Battery powered with rechargeable options
Megger PAT150 Specifications
General Specifications
| FEATURE | SPECIFICATION |
|---|---|
| Operating Temperature | 0 °C to +40 °C (32 °F to 104 °F) |
| Storage Temperature | -20 °C to +60 °C (4 °F to 140 °F) |
| Humidity | 90% RH @ +10 °C to +30 °C, 75% RH @ +30 °C to +60 °C |
| Operating Altitude | Up to 2,000m |
| IP Rating | IP40 (with front cover closed) |
| Battery Type | Eight AA LR6 cells, 12 V dc (Alkaline), 9.6 V dc (NiMH) |
| Weight (PAT120) | 1150g (instrument), 2370g (shipping) |
| Weight (PAT150) | 1300g (instrument), 2975g (shipping) |
| Dimensions (Instrument and Case) | 203 mm L x 148 mm W x 78 mm H (8 x 5.7 x 3.2 inches) |
| Dimensions (Instrument and Packaging) | 456 mm L x 178 mm W x 89 mm H (18 x 7.1 x 3.5 inches) |
Test Capabilities and Specifications
| TEST | SPECIFICATIONS |
|---|---|
| Continuity Test | Voltage: +4 V dc -0% / +30%, Current: +200 mA -0 % + 50 mA, Accuracy: ± 5% ± 3 digits, Resolution: 10 mΩ, Display Range: 0.01 to 19.99 Ω |
| Insulation Test | Voltage: 250 V dc and 500 V dc -0% +25%, Accuracy: ± 3% ± 10 digits, Display Range: 0.10 MΩ to 99.99 MΩ |
| Substitute Leakage Test | Voltage: < 50V ac, Frequency: 50 Hz, Accuracy: ± 5% ± 3 digits, Resolution: 0.01 mA, Display Range: 0.10 to 19.99 mA |
| Differential Leakage Current | Voltage: 230 V ac, Frequency: 50 Hz, Accuracy: ± 5% ± 3 digits ± 3 uA/A, Display Range: 0.10 to 19.99 mA |
| Touch Current Test | Voltage: 230 V ac, Frequency: 50 Hz, Accuracy: ± 5% ± 3 digits, Display Range: 0.10 to 3.99 mA |
| SELV Device Test | Voltage: 0 to 300 V ac, Accuracy: ± 3% ± 3 digits, Display Range: 0.1 to 300 V ac |
| Extension Lead Test | Voltage: 5 V, Conditions: Polarity Lead OK, Live/neutral shorted, reversed, open circuit |
| Portable RCD Test | Voltage: 230 V, Frequency: 50 Hz, Current Accuracy: +2 % to +8 %, Trip Time Accuracy: ± 1 % ± 1 ms, Display Range: 0 to 200 ms (1 x I), 0 to 40 ms (5 x I) |
| Main Supply Test | Frequency: 50 Hz, Voltage: 40 to 300 V ac, Accuracy: ± 3% ± 3 digits, Display Range: 40 to 300 V ac |
| Safety and Compliance | Designed to IEC 61010-1: 2012, Test leads to IEC 61010-031: 2005, Mains fuse protection to 250 V rms ac, EMC compliant with IEC 61326-1: 2012, IEC 61326-2-2: 2012 |
